Dell 10G SFP+ 850nm Transceiver Module WTRD1

The Dell™ SFP+ transceiver delivers fiber connectivity to extend the range of your network. This hot-pluggable transceiver with SFP (Small Form Factor Pluggable) footprint features a duplex LC connector. The Dell networking 10GBase-SR SFP+ transceiver provides 10GbE connectivity up to 300 m. Additionally, it provides a unique enhanced digital diagnostic monitoring interface, which allows real-time access to device operating parameters such as transceiver temperature, laser bias current, transmitted optical power, received optical power and transceiver supply voltage.

Product Specifications:

🗹 Generation: SR 850nm
🗹 Form Factor: Plug-in module
🗹 Cabling Type: 10GBase-SR
🗹 Data Transfer Rate: 10 Gbps
🗹 Fibre Type: Multi Mode Fibre (MMF)
🗹 Data Link Protocol: 10 GigE
🗹 Max Transfer Distance: 984 Ft
🗹 Part Number: WTRD1

Key Features:

* SFP+ transceiver module type
* Fibre LC Duplex connector
* Unique enhanced digital diagnostic monitoring interface provided
* 10 Gbps of data transfer rate
* 850 nm optical wave length
